Soft Grade
N660
Carbon Black N660 – General Purpose Furnace (GPF)
- Lower surface area compared to N-550, Medium-low structure, High modulus with suitable reinforcement, Good elasticity at higher hardness levels
Iodine Number
30 ± 5
g/kg
OAN
65 ± 5
ml/100g
NSA
32 ± 5
m²/g
Particle Size
61 - 100
nm
Technical Specifications
| # | Quality Specification | Test Method | Value |
|---|---|---|---|
| 1 | Iodine Adsorption Number | ASTM D1510 | 30 ± 5 g/kg |
| 2 | Oil Absorption Number (OAN) | ASTM D2414 | 65 ± 5 ml/100g |
| 3 | Oil Absorption Number (COAN) | ASTM D3493 | 59 ± 5 ml/100g |
| 4 | Pour Density | ASTM D1513 | 520 ± 20 kg/m³ |
| 5 | Heating Loss | ASTM D1509 | 1 % max |
| 6 | Toluene Solvent Discoloration | ASTM D1618 | 60 % min |
| 7 | pH | ASTM D1512 | 7.5 - 9 - |
| 8 | Fines Content (Q-Bag) | ASTM D1508 | 7 % max |
| 9 | Fines Content (Bag) | ASTM D1508 | 10 % max |
| 10 | Individual Pellet Hardness (Max 20) | ASTM D5230 | 50 cN |
| 11 | Individual Pellet Hardness (Ave 20) | ASTM D5230 | 10 - 40 cN |
| 12 | Sieve Residue No.35 US Std | ASTM D1514 | 10 ppm max |
| 13 | Sieve Residue No.325 US Std | ASTM D1514 | 1000 ppm max |
| 14 | Ash Content | ASTM D1506 | 0.75 % max |
| 15 | Sulfur Content | ASTM D1619 | 2 % max |
| 16 | NSA (Nitrogen Surface Area) | ASTM D6556 | 32 ± 5 m²/g |
| 17 | STSA (Statistical Thickness Surface) | ASTM D6556 | 30 ± 5 m²/g |
| 18 | Tint Strength | ASTM D3265 | ...... % |
| 19 | Particle Size | - | 61 - 100 nm |
All values are typical specifications. Certificate of Analysis (COA) provided with every shipment.
Primary Applications
Tire Carcass Layers
Tire Sidewalls
Mechanical Rubber Products
Packaging & Logistics
Jumbo Bags (Bulk)
Double Valve, PP/PE Material
- Bag Weight: 1,100 kg
- 20ft Container: 10 pallets / 11,000 kg
- 40ft Container: 20 pallets / 22,000 kg
- Full Truck: 22 pallets / 24,200 kg
Small Bags (Paper)
Double Layer Kraft Paper-PE Envelopes
- Bag Weight: 25 kg
- Pallet Weight: 1,100 kg
- 20ft Container: 8 pallets / 8,800-11,000 kg
- 40ft Container: 16 pallets / 17,600-22,000 kg
Worldwide Export: Full documentation including COA, MSDS, Packing List, and Commercial Invoice provided with every shipment. Custom packaging available upon request.
Documentation
